Awnapol® is a Premium Grade Corrugated Bitumen waterproof roofing sheet that is used for roofing applications on outbuildings, sheds, log stores, shelters and similar applications. The Awnapol® bitumen sheets simply overlap on width and length to reduce the need for cutting end sheets.
Why choose Awnapol Premium Bitumen sheets over Corrapol-BT Bitumen Sheets?
Awnapol is thicker and more robust than Corrapol-BT providing a slightly heavier duty and longer lasting product for the more challenging applications. Awnapol is available in 2 colours; black and green.
How many sheets will I need?
You can work out your Awnapol roof requirements with a simple calculation.
EXAMPLE CALC: If you had a roof that was 5 metres wide by 3 metres length (down the slope) you would work it out in two calculations.
STEP 1: First simply divide the width of your roof by the coverage width of a sheet. The coverage width of an Awnapol Roof Sheet is 855mm allowing for one corrugation overlap or 760mm if you are allowing for two corrugation overlaps.
EXAMPLE OF STEP 1 CALC:
5000mm ÷ 855mm = 5.85 = round up to 6 sheet widths
STEP 2: Secondly we need to work out the length requirements. Add your chosen sheet overlap distance and any required overhang to the length (slope), then divide this overall distance by the length of the sheets. Awnapol roof sheets are 2000mm long.
EXAMPLE OF STEP 2 CALC:
3000mm Length (slope) + 300mm overlap + 100mm overhand = 3400mm
3400mm total slope requirements ÷ 2000mm = 1.7 = round up to 2 sheet lengths
6 sheet widths x 2 sheet lengths = 12 sheets total
Still unsure? Don't worry, it's not always as simple as it seems so just Live chat to our team below for guidance.
What fixings and accessories do I need?
The good news is that our Premium Awnapol Bitumen Sheets are compatible with all our Corrapol-BT accessories, fixings and flashings. Please view our Exploded Project Images to see full details of the other items you will require for your roofing project, depending on the different types of roof. Below is a table showing you some common accessories that the majority of Awnapol Corrugated Roofs will require:
Where & Why are they needed?
|Rock N Lock Gable Flashing
|Essential for properly waterproofing your roof and protecting the gables, or sometimes called verges, from water leakage.
|A perfect finishing colour matching Ridge product for the top of any apex type roof. Also, check out the Super Ridge End Cap to suit!
- Material: Bituminous fibre
- Coverage Width: 855mm
- Sheet Length: 1000mm or 2000mm (Can be easily overlapped in length and width)
Related Blog Articles:
- Which Roofing Sheets Last Longest?
- Important Tips for Corrugated Roof Flashing
- 3m & 4m Corrugated Plastic Roofing Sheets - Sorted
Have more questions about our Awnapol Premium Corrugated Bitumen Sheeting?
Still unsure on what roofing materials you'll require for your project or have a lingering technical question? Use our online chat to speak to one of our product experts, who will be able to help you pick the perfect roofing products for your project. Alternatively, you can get in touch via email@example.com
